Owner’s Manual

GTX120/212 Guitar Amplifierwith

DSP & ChannelTracking

Congratulations!

You are now the proud owner of the Crate GTX120/212 amplifier. This rugged amplifier combines outstanding features with serious clean and distorted sounds. An easy to operate DSP section lets you dial in a variety of digital effects including reverbs, delays, octave and wah-wahs– with a separate level control. Crate’s uniqueChannel Tracking feature means that as you switch between channels and gains, the DSP automatically “tracks” the changes - your DSP settings for each channel are stored and automatically recalled! The suppliedthree-buttonfootswitch allows you to select channels, change the overdrive gain, and turn the DSP on and off by “remote control.”

Like all Crate products, your GTX120/212 is designed by musicians, and built using only the best components. Extensive testing confirms that this amplifier is the absolute best it can be.

In order to get the most out of your new amplifier, we strongly urge you to read the information contained in this manual before you begin playing.

And thank you for choosingCRATE.

TABLE OF CONTENTS:

The Digital Signal Processor . . . . . . . . . . . . .

. . . . . . . .3

Channel Tracking . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . .3

The Front Panel . . . . . . . . . . . . . . . . . . . . . . .

. . . . . .4, 5

Suggested Settings . . . . . . . . . . . . . . . . . . . .

. . . . . . . .6

System Block Diagram . . . . . . . . . . . . . . . . .

. . . . . . . .7

Technical Specifications . . . . . . . . . . . . . . . . .

back cover

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLEPARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

PRECAUCION

RIESGO DE CORRIENTAZO

NO ABRA

ADVERTENCIA: REDUCIR EL RIESGO DE FUEGO O CHOQUE ELÉCTRICO, NO LE EXPONE DE ESTE APARATO A LLUVIA O HUMEDAD. PARA DISMINUOIR EL RIESGO DE CORRIENTAZO. NO ABRA LA CUBIERTA.

NO HAY PIEZAS ADENTRO QUE EL USARIO PUEDO REPARAR DEJE TODO MANTENIMIENTO A LOS TECHNICOS CALIFICADOS.

ATTENTION

RISQUE D'ELECTROCUTION

NE PAS OUVRIR

ATTENTION: POUR REDUIRE D'ELECTROCUTION NE PAS ENLEVER LE COUVERCLE. AUCUNE PIECE INTERNE N'EST REPRABLE PAR L'UTILISATEUR. POUR TOUTE REPARATION, S'ADRESSER A UN TECHNICIEN QUALIFIE.

IMPORTANT SAFETY INSTRUCTIONS

•READ, FOLLOW, HEED, AND KEEP ALL INSTRUCTIONS AND WARNINGS.

•DO NOT OPERATE NEAR ANY HEAT SOURCE AND DO NOT BLOCK ANY VENTILATION OPENINGS ON THIS APPARATUS.

•DO NOT USE THIS APPARATUS NEAR SPLASHING, FALLING, SPRAYING, OR STANDING LIQUIDS.

•CLEAN ONLY WITH LINT-FREEDAMP CLOTH AND DO NOT USE CLEANING AGENTS.

•ONLY CONNECT POWER CORD TO A POLARIZED, SAFETY GROUNDED OUTLET WIRED TO CURRENT ELECTRICAL CODES AND COMPATIBLE WITH VOLTAGE, POWER, AND FREQUENCY REQUIREMENTS STATED ON THE REAR PANEL OF THE APPARATUS.

•PROTECT THE POWER CORD FROM DAMAGE DUE TO BEING WALKED ON, PINCHED, OR STRAINED.

•UNPLUG THE APPARATUS DURING LIGHTNING STORMS OR WHEN UNUSED FOR LONG PERIODS OF TIME.

•ONLY USE ATTACHMENTS, ACCESSORIES, STANDS, OR BRACKETS SPECIFIED BY THE MANUFACTURER FOR SAFE OPERATION AND TO AVOID INJURY.

•THIS APPARATUS DOES NOT OPERATE NORMALLY AND REQUIRES SERVICE WITH ANY PHYSICAL DAMAGE FROM IMPACT OR ANY EXPOSURE TO MOISTURE.

•SERVICE MUST BE PERFORMED BY QUALIFIED PERSONNEL.

•OUR AMPLIFIERS ARE CAPABLE OF PRODUCING HIGH SOUND PRESSURE LEVELS. CONTINUED EXPOSURE TO HIGH SOUND PRESSURE LEVELS CAN CAUSE PERMANENT HEARING IMPAIRMENT OR LOSS. USER CAUTION IS ADVISED AND EAR PROTECTION IS RECOMMENDED IF UNIT IS OPERATED AT HIGH VOLUME.

EXPLANATION OF GRAPHICAL SYMBOLS:

'DANGEROUS VOLTAGE'

EXPLICACION DE SIMBOLOS GRAFICOS:

= “VOLTAJE PELIGROSO”

EXPLICATION DES SYMBÔLES GRAPHIQUES:

'DANGER HAUTE TENSION'

'IT IS NECESSARY FOR THE USER TO REFER TO THE INSTRUCTION MANUAL'

=“ES NECESARIO QUE EL USUARIO SE REFIERA AL MANUAL DE INSTRUCCIONES.” 'REFERREZ-VOUSAU MANUAL D'UTILISATION'

GTX120/212 Guitar Amplifierwith

DSP & ChannelTracking

The Digital Signal Processor:

Crate’s Digital Signal Processing offers 16 exciting digital effects, accessible through the DSP Mode control. The effects are described below.

1

small room reverb

2

medium room reverb

3

large room reverb

4

concert hall reverb

5

short slapback w/small room reverb

6

medium delay w/plate reverb

7

long delay w/large room reverb

8

slow deep flange w/reverb

9

flange w/reverb & delay

10

slow chorus w/reverb

11

chorus w/reverb & delay

12

rotating speaker

13

octave down

Use the DSP Mode control to access

14

touch wah

any of the 16 built-indigital effects.

15

inverse wah

Use the Level control to mix in the

16

doubler

desired amount of each effect.

Channel Tracking:

Your Crate GTX120/212 gives you the power of Channel Tracking! Once you select a DSP setting for each channel, Channel Tracking recalls those DSP settings automatically – without changing the DSP controls! For example:

•Select the Clean channel. Set the DSP Mode to “8”(slow deep flange w/reverb)

•Select the Rhythm/Solo channel, Gain 1. Set the DSP Mode to “10”(slow chorus w/reverb)

(the setting for the Clean channel is now saved to memory)

• Select the Rhythm/Solo channel, Gain 2. Set the DSP Mode to “14”(touch wah)

(the setting for the Rhythm/Solo channel, Gain 1 is now saved to memory)

• Reselect the Clean channel (the setting for the Rhythm/Solo channel, Gain 2 is now saved to memory)

Now when you go back to the Clean channel, even though the DSP Mode was last set to “14” (touch wah), Channel Tracking automatically recalls the last setting for the Clean channel – in this example, “8” (slow flange). Change to the Rhythm/Solo channel, Gain 1, and “10” (chorus) is recalled. Change to the Rhythm/Solo channel, Gain 2, and “14” (touch wah) is recalled. That’s the power of Channel Tracking!

(Note: Even when the power is turned off, Channel Tracking still retains the settings – untilyou change them!)

3

GTX120/212 Guitar Amplifierwith

DSP & ChannelTracking

The Front Panel:

1

2

3

4

5

6

7

8

9

10

1: INPUT: Use this 1/4” jack to connect your guitar to the amplifier by means of a shielded instrument cable.

RHYTHM/SOLO CHANNEL: A high gain channel giving you sounds from a slight edge to serious overdrive.

2:RHYTHM GAIN 1: Use this control to adjust the amount of light distortion for the Rhythm/Solo channel. Gain 1 produces less intense distortion than Gain 2 (#3) and is active when the Rhythm/Solo Gain switch (#5) is in the out position.

3:SOLO GAIN 2: Use this control to adjust the amount of heavy distortion for the Rhythm/Solo channel. Gain 2 produces more intense distortion than Gain 1 (#2) and is active when the Rhythm/Solo Gain switch (#5) is depressed.

4:SHAPE: Use this control to “dial in” the tone for the Rhythm/Solo channel when Gain 2 is selected. Rotating the control counterclockwise enhances the mid frequencies, while rotating the control clockwise enhances the low and high frequencies.

5:RHYTHM/SOLO SWITCH: Use this switch to select which gain control is active for the Rhythm/Solo channel. With the switch in the out position, Gain 1 (Rhythm) is selected. When the switch is depressed, Gain 2 (Solo) is selected.

6:LOW: Use this control to adjust the low frequency level of the Rhythm/Solo channel.

7:HIGH: Use this control to adjust the high frequency level of the Rhythm/Solo channel.

8:LEVEL: Use this control to adjust the output level of the Rhythm/Solo channel.

9:CHANNEL SWITCH: Use this switch to select the desired channel. With the switch in the out position, the Clean channel is selected. When the switch is depressed, the Rhythm/Solo channel is selected.

CLEAN CHANNEL: A normal gain channel designed to give you sounds from crystal clear to medium distortion.

10:LEVEL: Use this control to adjust the output level of the Clean channel.

11:LOW: Use this control to adjust the low frequency level of the Clean channel.

12:MID: Use this control to adjust the midrange frequency level of the Clean channel.

13:HIGH: Use this control to adjust the high frequency level of the Clean channel.

14:DSP LEVEL: Use this control to adjust the amount of digital effect: in its fully counterclockwise position the signal will be “dry” (without any effect). As you rotate the control clockwise the amount of effect increases.

15:DSP MODE: Use this control to select one of the 16built-indigital effects. The effects are shown on page 3.

GTX120/212 Guitar Amplifierwith

DSP & ChannelTracking

11

12

13

14

15

16

17

18

16:INSERT: Use this jack to connect an external effects device to the amplifier. Use a stereo 1/4” male Y connector: ring = send, tip = return, sleeve = ground. (Refer to the illustration at the bottom of page 5.)

212

17:EXTERNAL SPEAKER: Use this jack to connect an external speaker to the amplifier. This jack is wired in series with the internal speaker(s) which remain active when an external speaker is connected.

18:POWER: Use this switch to turn the amplifier on (top of the switch depressed) and off (bottom of the switch depressed). The switch is illuminated when the amplifier is on.

19:AC LINE CORD (rear panel, not shown): This grounded power cord is to be plugged into a grounded power outlet, wired to current electrical codes and compatible with the voltage, power, and frequency requirements stated on the rear panel.Do not attempt to defeat the safety ground connection.

20:FUSE (rear panel, not shown): The fuse protects the amplifier from damages caused by a faulty AC power source and/or other problems. If the fuse opens, replace it ONLY with the same size and type. If fuses continue to fail, check the AC source – if the source is okay, contact your Crate dealer for service information.

21:CHANNEL SELECT / GAIN FOOTSWITCH JACK (rear panel, not shown): Use this jack to connect the 1/4” stereo plug on the footswitch cable to the three-button footswitch (supplied). This allows you to remotely switch between the Clean and Rhythm/Solo channels and between Rhythm Gain 1 and Solo Gain 2 of the Rhythm/Solo channel.

22:REVERB FOOTSWITCH JACK (rear panel, not shown): Use this jack to connect the 1/4” mono plug on the footswitch cable to the three-button footswitch (supplied). This allows you to remotely turn the DSP function on and off.

CONNECTING TO THE INSERT JACK:

The Insert jack (#16) allows you to patch an external effects device into the amplifier prior to its power amp stage. Use Crate’s STP201, STP202 or STP203 stereo-to-monoY cord or an adapter such as Crate’s YPP117 and two 1/4” mono signal cables to connect the effect as shown in the adjacent illustration.

Stereo-to-monoY-cord:

Y-adapterand 2 cables:

to Insert

TIP

RETURN

TIP

to Insert

jack

RING

SEND

RING

jack

SLEEVE

GROUND

SLEEVE

(STP201, 3'

(YPP117)

STP202, 6'

STP203, 9')

T

IR

PI

GN

T

IR

PI

GN

(1/4'-TO-1/4'

MONO CABLES)

to

to

to

to

effect

effect

effect

effect

'OUT'

'IN'

'OUT'

'IN'

jack

jack

jack

jack

External Effect

External Effect

5

GTX120/212 Guitar Amplifierwith

DSP & ChannelTracking

Suggested Settings:

'Sweet 'n Clean'

'Just a 'Lil Nasty'

'Pol

'Octave Down 'n Dirty'

'Wah Full H

'Mean & Obscene'

IN

GTX120/212 Guitar Amplifierwith

DSP & ChannelTracking

System Block Diagram:

CLEAN

INPUT

BUFFER

CHANNEL

CHANNEL

SELECT

LEVEL LOW MID HIGH

FLEX WAVE

STAGE

RHYTHM/SOLO

EQ

CHANNEL

SHAPE

ACTIVE

GAIN 2

GAIN 1

LOW HIGH LEVEL

SHAPE

MIX

DSP

LEVEL

POWER

MODE

DAMPING

CIRCUIT

Crate Gxt 212 Manually Engine

7

GTX120/212 Guitar Amplifierwith

DSP & ChannelTracking

GTX120/212 TECHNICAL SPECIFICATIONS:

Output Power Rating

120W RMS @ 5% THD, 4Ω , 120 VAC

Speaker Size and Rating

GTX120

(1) Custom Design 12”, 4Ω

GTX212

(2) Custom Design 12”, 8Ω

Input Impedance

470kΩ

Total System Gain

Overdrive Ch

Gain 1: 88dB, all controls @10; Gain 2: 110dB

Clean Ch

58dB, all controls @10

Maximum Input Signal Accepted

7 volts peak-to-peak

Rhythm/Solo Channel

Low Control

11dB range @ 80Hz

Shape Control

Proprietary Circuit

High Control

10dB range @10kHz

Clean Channel

Low Control

22dB range @ 80Hz

Mid Control

14dB range @ 600Hz

High Control

28dB range @ 10kHz

Power Requirements

120 VAC, 60Hz, 95VA; 100VAC, 50/60Hz, 95VA;

230VAC, 50Hz, 95VA

Size and Weight

GTX120

17-1/2”H x 20” W x 11” D, 34 lbs.

GTX212

21” H x 26.5” W x 11” D, 50 lbs.

The GTX120/212 is covered with a durable charcoal gray Tolex material: wipe it clean with a lint-freecloth. Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.

Crate gxt 212 manually for sale

Crate Gxt 212 Manually Download

Crate continually develops new products, as well as improves existing ones. For this reason, the specifications and information in this manual are subject to change without notice.

Crate Gx 212 Manual

Declaration Of Conformity

#34, Effective 01-01-2001

Manufacturer’s Name:

SLM Electronics

Production Facility:

11880 Borman Drive, St. Louis, MO 63146, USA

Production Facility:

700 Hwy 202 W, Yellville, AR 72687, USA

Shipping Facility:

1400 Ferguson Ave., St. Louis, MO 63133, USA

Office Facility:

1400 Ferguson Ave., St. Louis, MO 63133, USA

Product Type:

Audio Amplifier

Complies with Standards:

LVD:

92/31/EEC, 93/68/EEC, & 73/23/EWG

Safety:

EN60065

EMC:

EN55013, EN55020, EN55022, EN61000-3-2,

& EN61000-3-3

Supplementary information provided by: SLM Electronics - R & D Engineering

1901 Congressional Drive, St Louis, MO 63146, USA

Tel.: 314-569-0141,Fax:314-569-0175

www.crateamps.com

@2002 SLM Electronics, a division of St. Louis Music, Inc • 1400 Ferguson Avenue • St. Louis, MO 63133 47-476-07• 04/02
